Our Products
DUAL PLATE NRV
| Body | |
|---|---|
| Material | Cast Iron, IS:210 |
| Disc | |
| Type | CF8 |
| Sheet | |
| Type | EPDM Rubber Lining |
| Ends | |
| Material | Wafer type suitable for clamping between flanges as per |
| Testing | |
| Leakage Test | Tested at gravity pressure 0 drops Leakage Observed |
| Working Pressure | 0.5 kg/cm² |
| Body Test Pressure | 24 kg/cm² |
| Seat Test Pressure | 16 kg/cm² |
| Pressure | |
| Rating | PN-16 |
| Size Range | |
| Range | DN-50, DN-65, DN-80, DN-100, DN-150, DN-200 |
